NTE Electronics NTE4060B CMOS Integrated Circuit, 14-Stage Ripple Carry Binary Counter/Divider and Oscillator, 16-Lead DIP

Fully static operation

Diode Protection on All Inputs

Supply Voltage Range = 3.0V to 18V

Buffered Outputs Available from Stages 4 through 10 and 12 through 14

Common Reset Line

The NTE4052B (16-Lead DIP) 14-stage binary ripple counters with an on-chip oscillator buffer. The oscillator configuration allows design of either RC or crystal oscillator circuits. Also included on the chip is a reset function which places all outputs into the zero state and disables the oscillator. A negative transition on Clock will advance the counter to the next state. Schmitt trigger action on the input line permits very slow input rise and fall times. Applications include time delay circuits, counter controls, and frequency dividing circuits.
Brand: NTE Electronics, Model: NTE4060B
