Eminence American Standard Series ALPHA-6CBMRA 6.5" Midrange Speaker, 100 Watts at 8 Ohms

Out Of Stock

Be the first to review this product

Eminence

SKU: EZFB0089OBGNY

$72.49

Qty

Add to wishlist Add to compare

Quick Overview

Nominal Basket Diameter 6.5", 165mm Nominal Impedance 8 ohms Power Rating Watts 100W Music Program 200W Resonance 500.52HzUsable Frequency Range 500Hz - 4.3kHz Sensitivity 99.8dB Magnet Weight 4 ounce Gap Height 0.25", 6.35mm Voice Coil Diameter 1.5", 38.1mmResonant Frequency (FS) 501Hz DC Resistance (Re) 7.4 Coil Inductance (Le) 0.49mH Mechanical...

Nominal Basket Diameter 6.5", 165mm Nominal Impedance 8 ohms Power Rating Watts 100W Music Program 200W Resonance 500.52Hz

Usable Frequency Range 500Hz - 4.3kHz Sensitivity 99.8dB Magnet Weight 4 ounce Gap Height 0.25", 6.35mm Voice Coil Diameter 1.5", 38.1mm

Resonant Frequency (FS) 501Hz DC Resistance (Re) 7.4 Coil Inductance (Le) 0.49mH Mechanical Q (QMS) 9.09 Electromagnetic Q (QES) 1.83

Diaphragm Mass Inc. Airload (MMs) 7.6 gramsEfficiency Bandwidth Product (EBP) 273.2Maximum Linear Excursion (Xmax) 0.1mmSurface Area of Cone (Sd) 139.7 cm2Maximum Mechanical Limit (Xlim) 1.6mm

Lightweight neodymium 6.5 closed back midrange for pro audio or MI use. Great in bass guitar rigs.
Brand: Eminence, Model: ALPHA6CBMRA, Size: 6 Inch, 100 W

Eminence American Standard Series ALPHA-6CBMRA 6.5" Midrange Speaker, 100 Watts at 8 Ohms
