Dwyer Series 628 Industrial Pressure Transmitter, Range 0-15 psia, 628-00-GH-P1-E4-S1

Price For: Each Range: 30 to 0" Hg Vac Output: 4 to 20 mA DC Includes: Instructions Operating Temp.: 0 to 200 F Loop Resistance: 0 to 1300 Ohms Manufacturers Warranty Length: 1 year Housing: Stainless Steel Power Required: 13 to 30VDC Thermal Error: /-0.02% Wetted Materials: 316 SS and 316L SS Electrical Connections: Mini Hirschman Process Connection: 1/4" NPT

NEMA Rating: 4x Max. Pressure (PSI): 0 to 15 Accuracy: /-1% Country of Origin (subject to change): United States

Pressure Transmitter, 0-30\" psia, Accuracy 1% F.S., Output 4 to 20 mA DC, Power Required 13 to 30 VDC, Process Connection 1/4 In MNPT, Material of Construction Stainless Steel, Housing Stainless Steel, Operating Temp 0 to 200 F, NEMA Rating 4X, General Purpose Housing, Loop Resistance 0 to 1300 Ohms, Max Pressure 30 PSI, Thermal Effect /-0.02%
Brand: Dwyer
